CNC Lathe Horizontal Machining Center
Lathe machine, turning machine for auto rim丨car rims, car wheel hub, car rim, auto rim maker
- Product Introduction
Introduction
Both horizontal and vertical CNC machines offer a range of complex cutting and machining functions. While a vertically mounted machining center is more cost-effective and a good choice for basic production needs, the CNC Lathe Horizontal Machining Center operates at a higher rate of production and has gained popularity with higher machining accuracy. It is very suitable for processing various boxes and complex parts, so it is very popular in automotive, marine, and other fields.
Features
CNC Lathe Horizontal Machining Center is equipped with an automatic exchange table, so it can realize the automatic exchange of workpieces.
The highly integrated control panel has complete functions, which can make the operation of our equipment easier and more convenient.
Materials such as high-strength cast iron can further improve the stability of the machine tool, and the force of rigid cutting can also be fully guaranteed.
With a closed structure, the machining process of the CNC Lathe Horizontal Machining Center is safer and prevents water leakage.
| Specification | MACHINE MODLE | Single pole horizontal | |
| HTC-series | |||
| 800 | 900 | ||
| Spindle | Type | Belt/PL V-ribbed belt | Belt/PL V-ribbed belt |
| Max speed (rpm) | 2500 | 2500 | |
| Spindle nose type | A2-8 | A2-8 | |
| spindle bearing dia | 160 | 160 | |
| spindle taper | sin95(1:20) | sin95(1:20) | |
| spindle bore dia | Φ90 | Φ90 | |
| Controller | Controller and motor |
Fanuc 0i-TF Plus X-αiF22/3000 Z-αiF22/3000 B SP：αiL30/7000 |
Fanuc 0i-TF Plus X-αiF22/3000 Z-αiF22/3000 B SP：αiL30/7000 |
| X-axis motor power(KW) | 4 | 4 | |
| X-axis motor torque(N•M) | 22/64 | 22/64 | |
| Z-axis motor power(KW) | 4 | 4 | |
| Z-axis motor torque(N•M) | 22/64 | 22/64 | |
| main motor(rated/maximum) power(KW) | 30/37 | 30/37 | |
| spindle(rated/maximum) torque(N•M) |
|
|
|
| WORK RANGE | maximum rotary dia(mm) | Φ800 | Φ900 |
| maximum cutting dia(mm) | 22¹¹ | 26¹¹ | |
| maximum cutting length(mm) | 12¹¹ | 14¹¹ | |
| saddle rotary dia(mm) | Φ620 | Φ730 | |
|
|
X/Z-axis travel(mm) | -30～360/750 | -30～430/850 |
| X/Z-axis rapid moving(m/min) | 20/20 | 20/20 | |
| Worktable | Center height(mm) | 125 | 160 |
| The edge width(mm) | 480 | 520 | |
| Tool number | 10 | 10 | |
| Inside tool dia | Φ50 | Φ50 | |
| Maximum tool size(mm) | 32*32 | 32*32 | |
| adjacent exchange tool and lock time(sec) | 0.76 | 0.9 | |
| farthest exchange tool and lock time(sec) | 1.32 | 1.6 | |
|
|
X/Z Positioning(mm) | 0.01(full-travel) | 0.01(full-travel) |
| X/Z Repeatabiliting(mm) | 0.005(full-travel) | 0.005(full-travel) | |
| OTHER | The whole power(KW) | 55 | 55 |
| Coolant capacity(L) | 300/600(High flow of coolant optional) | 300/600(High flow of coolant optional) | |
| Air pressure required(MPa) | 0.65 | 0.65 | |
| size(length×width×height) | 4398X2163×2441 | 4598X2263×2541 | |
| net weight(kg) | 10500 | 11500 | |
