HBC Series Horizontal Milling And Boring Machine
PRODUCT INTRODUCTION This machine series is cross sliding table moving structure, boring spindle is made of advanced materials, after careful heat treatment to improve the surface hardness, wear resistance, rigidity, and precision preservation of the W boring shaft, it is mainly used for...
- Product Introduction
PRODUCT INTRODUCTION
This machine series adopts movable column, side-mounted spindle box and movable ram, and is equipped with a CNC rotary table (or a flfloor-standing platform). The X-axis of the machine tool adopts double-motor anti-backlash high-precision rack and pinion transmission form, and the other axes are driven by servo motors, precision reducers and high-precision ball screws. The X, Y, and Z axes all use high-precision grating rulers for closed-loop control to ensure higher positioning accuracy.
PRODUCT ADVANTAGES
● The spindle box adopts 2-stage gear transmission, in the low gear, the output torque is large, suitable for heavy cutting; while in the high gear, the output speed is high, suitable for high-speed cutting;
● The square ram is made of high quality ductile iron, and the Y axis is driven by double screw to compensate for the droop deformation caused by the boring bar and the square ram moving forward.
