HBF Series Floor Type Milling And Boring Machine
PRODUCT INTRODUCTION This machine series adopts movable column, side-mounted spindle box and movable ram, and is equipped with a CNC rotary table (or a flfloor-standing platform). The X-axis of the machine tool adopts double-motor anti-backlash high-precision rack and pinion transmission form,...
- Product Introduction
PRODUCT INTRODUCTION
This machine series adopts movable column, side-mounted spindle box and movable ram, and is equipped with a CNC rotary table (or a flfloor-standing platform). The X-axis of the machine tool adopts double-motor anti-backlash high-precision rack and pinion transmission form, and the other axes are driven by servo motors, precision reducers and high-precision ball screws. The X, Y, and Z axes all use high-precision grating rulers for closed-loop control to ensure higher positioning accuracy.
PRODUCT ADVANTAGES
● The spindle box adopts 2-stage gear transmission, in the low gear, the output torque is large, suitable for heavy cutting; while in the high gear, the output speed is high, suitable for high-speed cutting;
● The square ram is made of high quality ductile iron, and the Y axis is driven by double screw to compensate for the droop deformation caused by the boring bar and the square ram moving forward.
