HBP Series Planer Type Milling And Boring Machine

This machine series adopts movable and single column, horizontal bed, hanging upright spindle box, while equipped with cutting tools and workpiece cooling system. It is suitable for processing various large and medium-sized parts such as plate parts, disc parts, shell parts, mold etc. It can automatically, effificiently and accurately complete a variety of processes such as boring, milling

and drilling with 1-time clamping.

● The rotary table adopts servo motor drive cross roller bearing (bearing outer ring is gear ring) dual motor anti-backlash control, to achieve higher bearing capacity of the table; At the same time, it is equipped with angle grating ruler to meet the requirements of 8" high positioning accuracy for any indexing of the rotary table， it is also equipped with a 4-point positioning device, so that the indexing of the rotary table can meet the high-precision positioning requirements of ±4";

● The X, Y, and Z servo axes adopt the form of a servo motor directly connected to a precision planetary gearbox to drive a large-diameter, high-precision double-nut ball screw; the guide rail of the machine tool adopts roller type to maintain strong cutting rigidity.
